Home Lift

Name: Home Lift
Brand: KJ Elevator
Price: 720000.0 INR
Availability: InStock

Price 720000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Home Lift Specification

Machine Room Size
Not Required for MRL / 1500 mm x 1500 mm

Inclination
0 (Vertical)

Type
Home Lift

Car Dimension
Custom based

Pit Depth
150 mm - 300 mm

Door Opening Size
700 mm - 900 mm

Overhead Height
3000 mm (minimum)

Load Capacity
200-600 kg

Usage
Residential/Private Villas

Noise Level
<65 dB

Hoist Way Size
1500 mm x 1500 mm (minimum)

Voltage
220-415 V

Material
Stainless Steel / MS Powder Coated

Drive Type
AC

Power Supply
Electric

Speed
0.3-1.0 m/s

Max. Lifting Height
Up to 15m

Max. Lifting Weight
600 kg

Mechanism Type
Gearless Traction / Hydraulic

Working Temperature
-10C to 40C

Control Device
Microprocessor Based Controller

Safety Device
Safety Sensor

Capacity
2-6 Persons

Intercom Facility
Optional

Colour Options
Customizable Panel Colours

Floor Display
Digital / LCD

Door Type
Manual / Automatic

Lighting
LED Cabin Lighting

Flooring Material
Anti-skid PVC/Granite/Marble

Level Accuracy
5 mm

Operating Environment
Indoor / Outdoor

Emergency Alarm
Available

Control Panel
Integrated Microprocessor Control

Power Consumption
2-3 kW

Drive Control
VVVF (Variable Voltage Variable Frequency)

Max Stops
Up to 6 Floors

Home Lift Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
30 Days

Main Domestic Market
Delhi

About Home Lift

A Home lift isa vertical transportation device installed in a private home, designed to move people or goods between different floors. While elevators are more commonly associated with commercial buildings, residential elevators have become increasingly popular in larger or multi-story homes.

Advanced Safety and Smart Controls

This home lift includes a sophisticated safety sensor, integrated emergency alarm, and LED cabin lighting for streamlined operation and peace of mind. The VVVF drive control and microprocessor-based controller ensure precise level accuracy (within 5 mm) and quiet (<65 dB), smooth rides every time. Optional intercom facility enhances communication and safety for all users.

Customizable Design and Flexible Installation

Choose from a range of customizable cabin panel colors, anti-skid flooring materials (PVC, granite, or marble), and adaptable car dimensions to match your space. The lift fits hoist ways as small as 1500 x 1500 mm, requires minimal pit depth, and can be installed without a dedicated machine room (MRL option), making it suitable for various indoor or outdoor settings.

FAQ's of Home Lift:

Q: How is the home lift installed in residential spaces?

A: Installation requires a minimum hoist way size of 1500 mm x 1500 mm with a pit depth between 150 mm to 300 mm, and an overhead clearance of 3000 mm. The lift can be tailored for indoor or outdoor setups and does not need a separate machine room if you select the machine-room-less (MRL) configuration.

Q: What safety features does this home lift offer during emergencies?

A: The lift is equipped with a safety sensor, emergency alarm system, LED lighting for improved visibility, and an optional intercom facility to enable communication in emergencies. All systems are monitored by integrated microprocessor controls for swift response and enhanced safety.

Q: When should I opt for gearless traction versus hydraulic mechanism?

A: Gearless traction systems are ideal for higher efficiency, quiet operation, and lower maintenance, suitable for multi-floor installations up to 6 stops. Hydraulic drives are recommended for smoother low-speed rides and locations with specific architectural constraints. Both systems meet residential lift requirements.

Q: Where can the home lift be installed and what environment is it suited for?

A: This lift is engineered for both indoor and outdoor installation in homes or private villas, functioning reliably in temperatures ranging from -10C to 40C. Its robust design makes it suitable for a variety of household environments and weather conditions.

Q: What is the process for customizing the home lift's appearance and features?

A: Customization includes selecting cabin panel colors, finishes in stainless steel or powder-coated materials, anti-skid PVC, granite, or marble flooring, and optional digital or LCD displays. Our team collaborates with you to finalize dimensions, finishes, and features, ensuring the lift complements your interior.

Q: How energy efficient is the home lift, and what is its power consumption?

A: The lift operates on a power supply of 220-415 V and consumes only 2-3 kW, making it highly energy efficient for residential usage while delivering optimal performance and reliability.

Q: What are the primary benefits of installing this home lift in villas or private homes?

A: Key benefits include improved accessibility, customizable design to match decor, smooth and quiet operation, advanced safety features, and the flexibility to install up to 6 floors with a maximum carrying capacity of 600 kg, enhancing mobility and convenience without compromising on style.
